Hansgrohe Croma Select E Multi SemiPipe

Product features

Hansgrohe Croma Select E Multi SemiPipe Shower Set

consists of:

Hansgrohe Thermostat Ecostat Comfort with Shower Rail

• exposed installation
• adjustable hot water limiter
• safety lock at 40C
• outlets controlled via volume control/diverter and may not be used simultaneously
• rotating outlet control
• 1/2″ connection
• G 1/2″ threaded connection
• centre distance 150 mm12 mm
• height-adjustable hand shower bracket
• glider inclination angle can be adjusted by 45

Isiflex Shower Hose

• high-quality metal effect shower hose
• anti-microbial coating to reduce the presence of bacteria
• pivot connectors prevent hose from tangling
• kink-protected
• larger inner diameter of 8 mm for higher flow rates
• conical nuts at both ends
• shower hose: L: 1600 mm

Croma Select E Multi Hand Shower

• 3 spray modes: SoftRain (soft, caressing rain spray), IntenseRain (strong, vitalising rain spray), Massage (concentrated, pulsating water jet)
• comfortably switch between spray modes (Select)
• fully chrome-plated spray face
• limescale can be removed from the silicone naps with a simple wipe (QuickClean)
• shower head size: 110 mm
• with internal water conduction
• rinseable dirt filter
• 1/2″ connection thread

• maximum flow rate (at 3 bar): 16 litres per minute

Please note

• according to DIN 18534, areas behind fittings must be protected from moisture damage. Use special sealing tapes to ensure proper sealing. Please order separately. You will find suitable sealing tapes under accessories
• according to the manufacturer, suitable for instantaneous water heaters

SpecificationsItem number:27248400Series:Croma Select EVersion:without EcoSmartMaterial:metal/plasticColour:chrome/matt whiteShower hose length (mm):1600Height (mm):1000Width of hand shower (mm):110Depth of hand shower (mm):110Projection (mm):248Type of fitting:thermostatsType of installation:exposedShape:roundWater activation:by rotatingMax. water consumption of the hand shower at 3 bar (l/min):16Components:with shower railNo. of outlets:1 outletHand shower spray modes:3 jetsHandle postion:left & rightBath filler:without bath fillerShippingContains:exposed thermostatic shower mixer, hand shower, shower hose, shower rail, glider, fittingsPackaging type:ParcelpdfProduct data sheetpdfAssembly instructionspdfCare instructions
