Nostalgic and extraordinary: Axor Montreux bath mixer with hand shower
The Axor Montreux bath mixer with hand shower does not skimp on ornamentation. For nostalgia lovers and fans of the extraordinary!
Diverter on a grand scale
The magnificent design extends right down to the last detail: the cradle, on which the hand shower rests like an antique telephone receiver, the white hand shower handle, the elegant levers for hot and cold water – you will always discover new enchanting details in this shower set. The diverter with which you switch between the bath spout and the hand shower also deserves special attention: it is designed as a generous lever inscribed with a round plaque with the words “Shower”. Opulent!
Product features
AXOR Montreux Metal Shower Hose 1.25 m
- metal shower hose
- without plastic coating
- shower hose length: 1250 mm
- pivot joints on both sides
- kink-protected
- conical nuts at both ends
” >
- exposed design allows easy installation, all working parts are outside of the wall
- with escutcheons
- connection type: S-unions
- centre distance: 170 mm 44 mm
- spray mode: normal spray (extensive, rich jet)
- soothing full, soft water jet enriched with air (AirPower)
- limescale can be removed from the silicone naps with a simple wipe (QuickClean)
- maximum flow rate: 22 litres per minute at 3 bar
- operating pressure: minimum 1 bar / maximum 10 bar
- ceramic shut-off cartridges hot/cold 90
- maximum temperature cannot be adjusted on installation
- non-return valve
- integrated shower support
- designed to run two outlets
AXOR Montreux Hand Shower
- shower head size: 100 mm
- spray mode: RainAir (lush soft, enriched rain jet)
- maximum flow rate (at 3 bar): 16 litres per minute
- operating pressure: minimum 1 bar / maximum 6 bar
- metal cover
- grey spray face
- rinseable dirt filter
- 1/2″ connection thread
- large shower with optimum water distribution (XXL Performance)
AXOR Montreux Metal Shower Hose 1.25 m
- metal shower hose
- without plastic coating
- shower hose length: 1250 mm
- pivot joints on both sides
- kink-protected
- conical nuts at both ends
Please note
- according to DIN 18534, areas behind fittings must be protected from moisture damage. Use special sealing tapes to ensure proper sealing. Please order separately. You will find suitable sealing tapes under accessories
- suitable for instantaneous water heaters according to the manufacturer
SpecificationsItem number:16551000Series:MontreuxDesigner:Phoenix DesignMaterial:brassColour:chromeShower hose length (mm):1250Diameter of hand shower (mm):106Projection (mm):224Type of fitting:two handle mixersType of installation:exposedShape:roundWater activation:by rotatingMax. water consumption of the bath inlet at 3 bar (l/min):20Max. water consumption of the hand shower at 3 bar (l/min):14Components:without shower railNo. of outlets:2 outletsHand shower spray modes:1 jetHandle postion:left & rightBath filler:with bath fillerShippingContains:exposed two handle mixer, hand shower, shower hose, shower bracketPackaging type:ParcelpdfProduct data sheetpdfAssembly instructionspdfCare instructions
