AXOR Edge thermostatic module Select 680/100: for 5 outlets
With AXOR Edge thermostatic module Select 680/100 for 5 outlets, you have everything you need for a comfortable shower experience. At the touch of a button – water is running!
High-quality design – with hand shower
With the Select 680/100 thermostatic module from AXOR’s Edge range, you can look forward to a sophisticated shower system with a high-quality design and practical functions. For example, you can use several outlets at the same time. They are activated at the touch of a button, and you can set the water temperature and volume by simply rotating the knob. The safety lock is activated at 40C and protects against excessively hot temperatures. This is particularly beneficial in family households. The hand shower pampers body and soul with two different spray modes. The diverter is made by turning the shower head. Enjoy quality from AXOR!
Product features
Thermostatic Module
- suitable for 5 outlets
- multiple outlets can be used simultaneously
- outlet activation at a push of a button (Select)
- thermostat cartridge to regulate the temperature by turning it
- constant water temperature even with fluctuating water pressure
- adjustable temperature limiter
- safety stop at 40C to protect against accidentally hot temperatures (scalding protection)
- with integrated hose connection with shower bracket
Hand Shower with Shower Hose
- 2 spray modes: Rain (powerful, pattering rain jet, ideal for washing hair), MonoRain (exceptional, soothing relaxation jet)
- switch spray mode by rotating the shower head
- limescale can be removed from the silicone naps with a simple wipe (QuickClean)
- hose is kink resistant, flexible, easy-to-clean & with anti-twist protection
- shower hose length: 1250 mm
Please note
- please order concealed installation unit separately. This can be found in Accessories
- suitable for shower hoses with cylindrical nuts on both sides
SpecificationsItem number:46730000Series:EdgeDesigner:Jean-Marie MassaudMaterial:brass/metalColour:chromeShower hose length (mm):1250Hand shower length (mm):190Type of fitting:thermostatsType of installation:concealedShape:square/rectangularWater activation:by pressingMax. water consumption of the fitting at 3 bar (l/min):38Max. water consumption of the bath inlet at 3 bar (l/min):38Max. water consumption of the hand shower at 3 bar (l/min):14Max. water consumption of the overhead shower at 3 bar (l/min):38Components:without shower railNo. of outlets:5 outletsHand shower spray modes:2 jetsHandle postion:frontBath filler:without bath fillerShippingContains:
concealed shower thermostat, hand shower, shower hose, shower bracket, wall elbow
Packaging type:Parcel XLpdfProduct data sheetpdfTechnical drawings
